FLAT & CONTAINER
WAGONS
Technical Specification - Flat & Container
| WAGONS | PURPOSE | NO. OF WAGONS PER RAKE | GAUGE | AXLE LOAD | GROSS WEIGHT | TARE WT | PAYLOAD |
|---|---|---|---|---|---|---|---|
| BFNS | Carrying hot rolled/cold rolled coils, plates, sheets & billets | 43 | 1676 | 20.32 | 81.28 | 26.71 | 54.57 |
| BFNS22.9 | Carrying hot rolled/cold rolled coils, plates, sheets & billets | 43 | 1676 | 22.9 | 91.6 | 26.71 | 64.89 |
| BFNSM | Carrying Steel coil, sheets etc. | 58 | 1676 | 22.9 | 91.6 | 23.6 | 68 |
| BRN22.9 BRN22.9M1 |
Used for transporting rails, sleepers, etc. | 43 | 1676 | 22.9 | 91.6 | 23.2 | 68.292 |
| BRNA BRNAHS BRNAM1 |
Used for transportation of 26mtrs long rails | 43 | 1676 | 20.32 | 81.28 | 23.543 | 57.737 |
| BRNA-EUR | Used for transportation of long welded rails upto 260 mtrs long | 18 | 1676 | 20.32 | 81.28 | 31.77/27.87 | 49.51/53.41 |
| BLC (Acar + Bcar) |
Carrying Freight Containers | 45 (18 Acar + 27 Bcar) |
1676 | 20.32 | Acar 80.1 Bcar 79 |
Acar 19.1 Bcar 18 |
Acar 61 Bcar 61 |
| BLCM (Acar + Bcar) |
Carrying Freight Containers | 45 (18 Acar + 27 Bcar) |
1676 | 22 | 88 | Acar 19.1 Bcar 18 |
Acar 68.9 |
| BLCS (Acar + Bcar) |
Carrying Freight Containers | 45 (18 Acar + 27 Bcar) |
1676 | 25 | 100 | Acar 19.2 Bcar 18.7 |
Acar 80.8 Bcar 81.9 |
| BLSS (Acar + Bcar) |
Carrying Freight Containers | 48 (4 Acar + 44 Bcar) |
1676 | 25 | 100 | Acar 18.85 Bcar 17.6 |
Acar 81.15 Bcar 82.4 |
Stringent Quality Control
Besco Limited follows rigorous quality control processes at every stage of manufacturing, ensuring each wagon meets Indian Railways standards and delivers consistent performance across tough operating conditions.
Advanced Material Selection
Wagons are built using high-grade corrosion-resistant steels and certified structural materials, enhancing durability, load-bearing capacity, and resistance to wear in extreme environments.
Precision Engineering & Welding
Utilizing precision CNC machining and robotic welding, Besco guarantees dimensional accuracy, structural integrity, and superior weld finish for enhanced wagon reliability and longevity.
Comprehensive Testing & Certification
Each wagon undergoes thorough mechanical testing, ultrasonic flaw detection, and load simulation trials, followed by certification from authorized railway inspection agencies to ensure unmatched safety and quality.
